Thermocouple Parts Ceramic Terminal Block D-8p-C

Brand Name : GME

Certification : CE

Place of Origin : China

MOQ : 50pcs

Payment Terms : T/T, Western Union, MoneyGram, L/C

Supply Ability : 100000 pcs per Month

Delivery Time : 7~10 working days

Packaging Details : cartons， pallet

Power Source : Electric

Dimension : Customized

Sheath material : aluminum alloy

explosion proof grade : dIIBT1 ~ T6

Supply : OEM

Wire entry : M20*1.5,M22*1.5,G1/2"

Protection level : IP 65

Usage : Industrial

Contact Now

thermocouple parts Ceramic terminal block D-8p-C

Description:

We are the very die-casting and mold factory that produce aluminum parts, zinc parts, plastic parts for all ranges. We have technical in outo parts, garden tools, safety belt parts, railway optical cable junction box, shell of temperature sensor, injection plastic parts, etc. And we focus on offering aluminum thermocouple heads together with the ceramic blocks.

Specification:

property

Item	Unit	zirconia ceramic	99% alumina ceramic	96% alumina ceramic	95% alumina ceramic	steatite ceramic	mullite ceramic	cordierite ceramic
Bulk Density	g/cm3	6	3.8	3.7	3.6	2.8	2.2	2.3
Thermal Conducivity	w/m.k	10	19-30	16-28	14-24	2-3	2-6	1.3-1.8
Resistance to Thernak Shock, minimum	TKε	70	150	140	140	80	150	300
Water Absorption	%	0	0	0	0	0	12	12
Withstand Voltage, Minimum	kv	15	20	18	18	20	25	-
Flexural Strength	mpa	1000	300	280	240	120	120	30
Sinterring Temperature	℃	1500	1670	1600	1600	1250	1250	1250
Maximum Working Temperature	℃	1200	1500	1200	1200	800	1000	1000

Thermocouple Parts Ceramic Terminal Block D-8p-C

Product Tags:

IP65 Thermocouple Ceramic Terminal Block

Ceramic Terminal Block D-8p-C

Aluminum Alloy Thermocouple Parts
